| Items | Description |
| INPUT (PV) |
| Maximum PV Input Power | 10.5kW |
| Maximum PV Input Voltage | 600V |
| Start Up Voltage | 1OOV |
| MPPT Voltage Range | 100V~550V |
| Number of MPP Trackers | 2 |
| Number of Strings Per MPPT | 2/1 |
| Max PV Input Current | 4OA/20A |
| OUTPUT (AC) |
| Rated Output Power | 7kW |
| Maximum Output Active Power | 7.7kW |
| Maximum Output Current | 35A |
| Rated Voltage | 23OV |
| Rated Frequency | 50Hz/60Hz |
| THDi(@Rated Power) | <3% |
| Power Factor | 0.8 leading ~ 0.8 logging |
| BATTERY |
| Battery Type | Lithium, Lead Acid |
| Battery Voltage Range | 40V~60V |
| Maximum Charge/Discharge Current | 175A |
| OUTPUT (EPS) |
| Max Output Power | 7.7kVA |
| Maximum Output Current | 35A |
| Peak Output Power, Time | 14kW,10s |
| Rated Voltage | 230V |
| THDv(@Rated Power) | <3% |
| Switch Time | <10ms |
| EFFICIENCY |
| Maximum Efficiency | 98.00% |
| European Efficiency | 97.50% |
| Battery Charge/ Discharge Efficiency | 97.00% |
| PROTECTION |
| DC Reverse Polarity | Yes |
| nsulation Resistance Monitoring | Yes |
| Ground Fault Monitoring | Yes |
| Over Current/Over Voltage Protection | Yes |
| Battery Soft Start Protection | Yes |
| AFCI Protection | Optional |
| Surge Protection | Type II |
| COMMUNICATION |
| Display | LCD |
| Communication | RS485/CAN/WIFI/4G/BLUETOOTH |
| GENERAL DATA |
| Dimension (W*H*D) | 440*534*240mm |
| Weight | 32kg |
| Operating Temperature Range | -30°C to +60°C |
| Self Consumption | <10W |
| Topology | High Frequency Insolation (For Battery) |
| Protection Degree | IP66 |
| Relative Humidity | 0~100% |
| Maximum Operating Altitude | 4000M |
| Cooling Method | Smart Forced Air Cooling |
